I have two tanks from KP the tanks have:

(2) 3/8" ports on each end
(2) 1/2" ports on each side
(1) 1/4" port on the bottom

My questions are, Will one 3/8" line per two fill valves be significantly slower on the fill than each fill valve having it's own 3/8" line from the tank?

My reason is. I was going to tee the rear valves off of the tank, meaning both rear fill valves would share a single 3/8" port.

For the front I was going to run a single 3/8" line to the front valves.

Would it be faster and and more beneficial to run individual lines to the front?

Mega Confused, any input will be appreciated!!!



[wagon b0y]

one line is enough :imo unless you are trying to hop. If you are worried, just run a single 1/2" line to the front.

On mine i ran a single 3/4" line to the front to feed both 3/4" fill valves. It would be a pain in the ass to run 2 3/4" lines all the way to the front.



[.ONTHEAIR.]

def not trying to hop. Im also trying to keep everything 3/8's. So a single 3/8" to the front would be fast enough to air up quick?



[wagon b0y]

yup that will be good enough. You going to run a 175 or 200psi pressure switch?


I don't even know why i ran 3/4". It was a pain in the ass and expensive. I should have ran like dual 1/4" :crazy:



[.ONTHEAIR.]

165 on 200 off.



[.ONTHEAIR.]

Does the pressure switch have to be mounted in the tank, taking up a port? Can I tee it in somewhere, like on the union for the rear valve block?



[wagon b0y]

Does the pressure switch have to be mounted in the tank, taking up a port? Can I tee it in somewhere, like on the union for the rear valve block?

as long as it is on the tank pressure side



[foedoeblaza]

i have my valves all hooked together with 1, 1/2" line feeding them then 3/8 to each bag. not super fast but not super slow either



[Carilliterate]

Someone should make a doodle of this to clarify please.



[.ONTHEAIR.]

ok! on I have no idea WTF a doodle is but it sounds gay as shit. Two I am running the rear valves tee'd off the tank with all 3/8" plumbing. The front will have a single 3/8" line running up the frame rail and into the front valve assembly. Are my fill speeds gonna be hella slow?



[98gmajb]

I'm assuming doodle = shitty quick drawing.



[Carilliterate]

I'm assuming doodle = shitty quick drawing.

yeah a sketch of some sort.



[oldschoolchevy]

I ran 1/2 inch lines an 3/8 vavles an it was too fast to I have to dump an fill controls.



[.ONTHEAIR.]

yeah im not looking to hop or shoot someone throught the roof. single 3/8" line feeding both fills should be straight then!



[oldschoolchevy]

yeah im not looking to hop or shoot someone throught the roof. single 3/8" line feeding both fills should be straight then!

It will be the perfect speed imo.

Btw what size valves are you runing?



[canadakustom]

on mine every thing is 3/8 lines and valves and its fast enought for me. i ran on single 3/8 line from the tank to a t for the front valves its working good.. the only 1/2 line i have is from my york compressor back to the tank.



[SMiGGs]

x2 on the shitty sketch
